IM60 IM60-2 IM360

Inclinometers with analog output

IM60 IM60-2 IM360

Inclinometers with analog output

Every inclination becomes precise, reliable data.
IM60 and IM360 measure the angle and convert it into a continuous signal.

IM60 and IM360 inclinometers measure the inclination angle relative to gravity and convert it into a continuous analogue signal.
The solid-state sensor, with no moving parts, provides resistance to shock and vibration and long-term reliability.
Compact dimensions and the available configurations allow easy integration into industrial applications and control systems.

KEY BENEFITS
	Solid-state sensor
	Shock and vibration resistant
	No moving parts
	Analogue output
	Compact design
	Custom calibration

APPLICATION FIELDS
	Cranes & aerial platforms
	Construction & agricultural machinery
	Levelling systems
	Buildings & structures
	Photovoltaic systems
	Cutting blades

Photogallery


— CUTTING BLADES	— INDUSTRIAL AUTOMATION

—
SOLAR TRACKING


— WIND ENERGY	— MOBILE PLATFORMS

CONNECTOR OUTPUT
Frontal view	Top view

CABLE OUTPUT
Frontal view	Top view

EMC 2014/30/EU

Analogue output 4-20mA ÷ 0-10Vcc

Case ABS

Electric connection cable length 2,5,10 meters or connector

IM360: Linearity ±0,6°

IM360: Measure angle 0-360°

IM60-2: Linearity ± 0,6°

IM60-2: Measure angle ± 60° 2 axis

IM60: Linearity ±0,5° -45° ÷ +45°
±1° -60° ÷ +60°

IM60: Measure angle ± 60°

Power supply 24 Vdc ±20% - max 150 mA

Protection degree IP66

Relative humidity 10÷90 %

Repeatibility ±0,05°

RoHs 2011/65/UE

RoHS Directive 2011/65/UE

Working temperature -10÷70 °C

VERSIONS
IM60 SINGLE AXIS	IM60-2 TWO AXIS	IM360 SINGLE AXIS
MEASURING RANGE ±60°	MEASURING RANGE ±60° X / ±60° Y	MEASURING RANGE 0÷360°

ANALOGUE OUTPUT	ANALOGUE OUTPUT	ANALOGUE OUTPUT
IM60-I = 4–20 mA	IM60-I2 = 4–20 mA	IM360-I = 4–20 mA
IM60-V = 0–10 Vdc	IM60-V2 = 0–10 Vdc	IM360-V = 0–10 Vdc
TOLERANCE	TOLERANCE	TOLERANCE

Reference axis 0°, max. 0–10° misalignment on the secondary axis	Mounted at 0° on both reference axes, 0–10° tolerance	Reference axis 0°, max. 0–10° misalignment on the secondary axis
